Fusion MS-RA60 Marine Stereo is a compact marine head unit designed to provide reliable onboard entertainment with simple controls, flexible audio sources, and independent sound management for two zones. It is suitable for boats requiring an easy-to-use boat stereo for music from Bluetooth-enabled devices, AM/FM radio, an auxiliary source, or DAB+ radio where supported. Its modern front panel includes a 2.3-inch perimeter-bonded monochrome LCD, providing a clear interface for source selection, track information, volume adjustment, and audio-zone control.

This Fusion marine stereo uses a Class-D amplifier to power up to four 4-ohm speakers across two amplified zones. It delivers a peak output of 180 watts, with a rated output of 22 watts RMS × 4 at 4 ohms when supplied with 14.4 V input and measured at less than 10% total harmonic distortion. Fusion Multi-Zone™ Technology allows separate volume control for two areas of the boat, making it possible to adjust the listening level for spaces such as the helm and cockpit independently. Zone 1 also provides left and right line outputs and a mono subwoofer output for connection to compatible external amplification.

Bluetooth® connectivity lets users stream music wirelessly from a compatible smartphone, tablet, or other Bluetooth audio device. The specified Bluetooth wireless range is up to 30 ft, while ANT® connectivity operates at up to 10 ft. Fusion-Link™ integration provides additional control options through a compatible smart device, Garmin multifunction display, or Garmin watch. The Garmin Audio app can also deliver over-the-air software updates through Bluetooth, helping users update the stereo without removing it from the installation.

The MS-RA60 supports AM, FM, Bluetooth, and one auxiliary source. It is also DAB+ ready in supported regions, although appropriate DAB equipment may be required. Physical connections include one RCA auxiliary input, one Motorola-type AM/FM antenna port, four speaker connections for two amplified zones, and one Zone 1 RCA pre-out covering left, right, and subwoofer channels. The RCA pre-out, line output, and subwoofer output require external amplification.

Designed specifically as a marine audio system component, the stereo’s front panel has IPX6 and IPX7 water ratings when correctly installed. These ratings apply only to the front panel, so correct mounting and installation remain important. The perimeter-bonded LCD is designed to help reduce condensation and improve display visibility in changing marine conditions. Its operating temperature range is 32° to 122°F (0° to 50°C), making it appropriate for many enclosed helm stations, dashboards, cabins, and open boat consoles when installed according to the manufacturer’s instructions.

The unit operates from a 10.8–16 VDC electrical supply and has a maximum current specification of 15 A. It measures 6.18″ × 2.68″ × 4.06″ (156 × 68 × 103.2 mm) and weighs only 0.7 lbs (316 g), allowing it to fit neatly into space-conscious marine dashboards. A compass-safe distance of 5.9″ (150 mm) should be maintained when planning its location. Its interface supports Dutch, English, French, German, Italian, and Spanish.

Key Features:

• Fusion MS-RA60 Marine Stereo provides Bluetooth streaming, AM/FM radio, an auxiliary input, and DAB+ readiness in one compact marine head unit.
• Class-D amplifier supports four 4-ohm speakers across two amplified audio zones.
• Delivers 180 watts peak power and 22 watts RMS × 4 at 4 ohms with 14.4 V input and less than 10% THD.
• Multi-Zone™ Technology provides independent audio control for two areas of the boat.
• Fusion-Link integration enables compatible control from a smart device, Garmin multifunction display, or Garmin watch.
• Over-the-air software updates are available through the Garmin Audio app using Bluetooth connectivity.
• The 2.3-inch perimeter-bonded monochrome LCD provides a clear, straightforward control interface.
• The front panel is rated IPX6 and IPX7 when the marine stereo is correctly installed.
• Includes a Zone 1 RCA pre-out with left, right, and mono subwoofer connections for use with external amplification.
• Operates on 10.8–16 VDC and supports a multilingual user interface.

Applications / Suitable For:

• Fusion MS-RA60 Marine Stereo is suitable for boats needing a compact two-zone boat audio system with wireless music streaming and radio playback.
• Recreational boats, fishing boats, centre consoles, bowriders, cruisers, and other compatible leisure craft.
• Helm, dashboard, cockpit, cabin, or console installations with an appropriate mounting location and 12V-class DC electrical system.
• Marine audio installations using up to four 4-ohm speakers divided between two independently controlled zones.
• Boat owners who want Bluetooth audio streaming from compatible smartphones or tablets.
• Systems requiring AM/FM radio, an auxiliary audio input, or DAB+ reception with the appropriate equipment in supported regions.
• Audio upgrades requiring Zone 1 line-level and subwoofer outputs for compatible external amplifiers.

FAQs:

Q: Can the Fusion MS-RA60 Marine Stereo control two audio areas separately?
A: Yes. Multi-Zone Technology supports two amplified zones, allowing the volume to be adjusted independently for different areas of the boat.

Q: Can I stream music from my phone to this marine stereo?
A: Yes. The stereo supports Bluetooth wireless audio from compatible devices, with a specified operating range of up to 30 ft.

Q: Is the front of the Fusion MS-RA60 water-resistant?
A: Yes. Its front panel is rated IPX6 and IPX7 when properly installed; these ratings do not apply to the entire rear of the unit.

Q: Does the MS-RA60 support an external amplifier or subwoofer?
A: Yes. Zone 1 provides left and right line outputs and a mono subwoofer output, all of which require compatible external amplification.
